MS40

MS40

This slip ring with silver to silver contact is designed for low signals.
With V-goove (90°) and raisen barrier; flexible, with color-coded silverplated
lead wire, compact in size and diameter.
High protection rate.



Technical specifications

ModelRings N° Max RPM VoltCurrent AmpExternal Diameter
MS40712240 VAC10165

Features

• Standard degree of protection IP65
• Working temperature from -35°C to + 80°C
• Circuit resistance 100mΩ with leads lenght of 300mm
• Insulation resistance of 100MΩ at 500VDC
• Noise 20mΩ Max

Data sheet

Download the data sheetScarica la scheda tecnica del prodotto
